| Specifications |
| GENERAL |
| General specifications |
Meets Inmarsat maritime specifications and
SOLAS Resolution XI-2/6 requirements |
|
Meets LRIT performance standard |
| INMARSAT mini-C TRANSCEIVER |
| Antenna specifications |
Inmarsat-C/GPS omni-directional antenna
RHC polarised
G/T: -23.7dB/K at 5° elevation
EIRP: 7dBW at 5° elevation
Elevation angle: -15° to 90° |
| Operating frequencies |
Rx: 1525.0 - 1559.0MHz*
TX: 1626.5 - 1660.5MHz*
GPS: 1575042MHz
*Inmarsat frequencies:
Rx: 1525.0 - 1545.0MHz
Tx: 1626.5 - 1646.5MHz |
| GPS module |
12-Channels. 1 sec update rate
15m RMS accuracy |
| Solar radiation |
Maximum flux density: 1200W/㎡ |
| Precipitation |
Up to 100mm/hour, droplet size 0.5 to
to 4.5mm at wind speed up to
200km/h(124mph) |
| Ice |
Up to 25mm |
| IP rating |
Lloyds approved for IP66
Tested for IP68 by Thrane & Thrane |
| Temperature range |
Operating: -35°C to 55°C
Storage: -40°C to 80°C |
| Fuse |
Self recovering poly fuse |
| POWER SPECIFICATIONS |
| Power source, floating |
Operating: 10.5V - 32V
DC Nominal: 12V - 24V
(at max. 20m cable) |
| Power consumption |
Rx: 1.8W (stand by)
Tx: 23W (at 12V DC supply) |
| SATELLITE COVERAGE SPECIFICATIONS |
| General |
Compatible with the new Inmarsat I4
satellite generation.
Automatic ocean shift for global coverage.
24 hour scanning for strongest signal; scanning on signal loss |
| DIMENSIONS AND WEIGHT |
| TT-3026M mini-C Transceiver |
Widest diameter: 163mm (6.4”)
Height: 146mm (5.7”)
Weight: 1.1kg (2.4lbs) |
